Can I mix surround sound in a browser?

Yes. KUON DAR 3D places sources on a top-down panner and renders 5.1, 7.1.4, 9.1.6 and 22.2 beds as 24-bit multichannel WAV, entirely in the browser. Speakers carry ITU-R BS.2051 labels. No install and no upload.

Can I export ADM / BW64 from a browser?

Yes. KUON DAR 3D writes BW64 with ds64, chna and axml chunks following ITU-R BS.2076-2 and BS.2088, in both channel-based (DirectSpeakers) and object-based (Objects) form. Object automation is written as timed audioBlockFormat entries at 0.2 second resolution. This is a first release, so verify ingest in your own toolchain.

How do I record movement of a sound source?

Press record and move the source by hand while the mix plays; the path is captured every frame and thinned to 40ms keyframes. There are also five preset paths (orbit, sweep, spiral, approach, flyby) with adjustable duration, and every keyframe can be retimed, edited or deleted on the timeline.

Can I synthesize a pickup pattern from omni microphone recordings?

Yes. Directivity development synthesizes omni, wide cardioid, cardioid, hypercardioid or figure-8 from a two-omni AB stereo recording, after the session. Enter the capsule spacing and temperature to see the pattern at each frequency and the upper limit of the controllable band; above it the sound blends back to the original, and low-frequency correction is capped to keep noise in check. Includes instant A/B against the original and 24-bit WAV export.

Can I listen in binaural before exporting?

Yes. Monitoring switches between binaural and stereo. Binaural uses the browser HRTF, so nothing needs to be installed. The same renderer is used for the binaural export.

The studio opens with a free account. To produce and export, choose the Concerto plan (1980 JPY per month, every Kuon app) or buy DAR 3D outright (29800 JPY one-time, future updates included). Customers outside Japan see local-currency pricing at checkout.

KUON DAR 3D · SPATIAL AUDIO STUDIO

Put the soundall around the listener —and move it.

The immersion stereo can’t reach — in a single browser tab. Monitor in binaural; export 5.1 / 7.1.4 / 9.1.6 / 22.2, ADM / BW64, and ambisonics.

Open the studio See features

Concerto (¥1,980/mo) or buy outright for ¥29,800 · no install · your audio never leaves your device

5.1 → 22.2ADM / BW64 exportAmbisonics (ambiX)Directivity developmentIn-browser · no uploadNo install4 languages

One place, two crafts.

MUSICIANS & ARTISTS

Bring the listener inside the music.

Voice in front, strings overhead, reverb behind. Move by hand while it plays and the sound travels with your phrasing. No expertise required.

RECORDING ENGINEERS

Your deliverables, the short way.

Beds from 5.1 to 22.2, ADM/BW64 with object motion, ambisonics for VR, binaural — all in-browser. Exports are 24-bit; ADM and ambisonics are a first release, so please verify ingest in your own toolchain.

GESTURE RECORDING

Perform the space, don’t program it.

Instead of typing numbers or drawing curves, move a source by hand while it plays — that motion becomes the keyframes. Presets (orbit CW/CCW, sweep, spiral, approach, flyby), smooth interpolation, and a timeline for fine edits. Whatever you record is baked into every export format.

A hand tracing an orbit of light through space

An AB pair of omni microphones set up before a grand piano in a hall

DIRECTIVITY DEVELOPMENT

Record omni first.Decide the pattern later.

From a two-omni AB stereo recording, synthesize the pickup pattern after the session: omni, wide, cardioid, hypercardioid or figure-8, with reversible direction and instant A/B against the original. Like developing a photograph — decide after you record.

Enter the capsule spacing and the room temperature to see the pattern at each frequency. The physics is shown honestly: control has an upper frequency limit, above which the sound blends back to the original.

What you can export

Binaural WAV

For headphones — the motion path is baked in with smooth interpolation.

Surround / immersive beds

5.1, 7.1.4, 9.1.6, 22.2 as multichannel WAV.

ADM / BW64

The professional interchange format (ITU-R BS.2076 / 2088). This is a first release — please verify ingest in your own toolchain.

Object ADM (timed paths)

Each source as an object — its motion travels with the master.

Ambisonics (ambiX)

For VR, 360 video and games — ideal for rotating fields.

Stereo 2.0

Down to everyday stereo, with the space intact.

Three steps

Bring in

Drag in your stems. Auto-placed by role.

Place & move

Drag on the top-down view. Move while it plays — the motion is recorded.

Export

Choose binaural, surround, ADM or ambisonics and download.

Your work stays on your device.

Loading, placing, monitoring and exporting all happen in the browser. Your audio is never sent to a server.

Two ways to get it.

SUBSCRIPTION

¥1,980 /mo

The Concerto plan — every Kuon app including DAR 3D. Cancel anytime.

View plans

ONE-TIME PURCHASE

¥29,800

For those who want DAR 3D for the long run. One payment; future updates included. Customers outside Japan see local-currency pricing at checkout.

Open the studio to buy

INCLUDED WITH THE MICROPHONE

If you buy a Kuon stereo microphone, X-86S or P-86S, DAR 3D comes with it. It opens with the password in your confirmation email, together with ACTOR, FIELD and NORMALIZE.

See the microphones

FAQ

Do I need plugins or an install?

No. Everything runs inside your browser — no software, no plugins.

Can I use it for Dolby Atmos work?

You can export ADM / BW64 with object motion — the professional interchange format that interoperates with Atmos (verify final ingest in your toolchain).

Does it work for VR / 360 video?

Yes — export first-order ambisonics (ambiX, ACN/SN3D).

How do I add motion?

Move a source by hand while it plays and your performance is captured. There are presets (orbit, sweep, spiral, approach, flyby) and a timeline for fine edits.

Are my files uploaded?

No. Loading, placing and exporting all happen on your device; your audio is never sent to a server.

Can I change the pickup pattern after recording with omni mics?

Yes. Directivity development synthesizes omni, wide, cardioid, hypercardioid or figure-8 from a two-omni AB recording, after the fact. Enter the capsule spacing to see the controllable band; above it the sound blends back to the original. Low-frequency correction can raise the noise floor slightly.

Can I use it alongside my DAW?

Yes — bring stems from your DAW and use DAR 3D just for spatial placement and export.

How much is it?

The studio opens with a free account. To produce and export, choose one of two ways: the Concerto plan (¥1,980/month, every Kuon app) or a one-time purchase of DAR 3D (¥29,800, future updates included). Customers outside Japan see local-currency pricing at checkout.

Deliver the music — space and all.

Open KUON DAR 3D
